涂布機涂布前，將清潔的，繃好網的網版從涂布機前面裝入，有的機型也可從側面裝入網版。在為大幅面網框設計的機型中，側面裝版更為常見，因為網框大且笨重，側面裝版，可使抬升量和搬動量小一些。在自動絲網涂布機與其他自動絲網處理設備（如清潔設備、再*設備、干燥裝置和顯影機）聯機運行時，從側面裝版更為便利。
Before coating, load the clean and stretched screen from the front of the coater, and some models can also load the screen from the side. In the models designed for large format mesh frames, side mounting is more common, because the mesh frames are large and bulky. Side mounting can reduce the lifting and moving amount. When the automatic screen coater is running online with other automatic screen processing equipment (such as cleaning equipment, re * equipment, drying device and developer), it is more convenient to install the plate from the side.
涂布機的開機程序：
Startup procedure of coater:
1、合上總電源開關及控制柜上電源開關；
1. Close the main power switch and the power switch on the control cabinet;
2、在張力控制器上設定好初始值（一般為180~280）及分頻數（通常為20~50）；
2. Set the initial value (generally 180 ~ 280) and frequency division number (usually 20 ~ 50) on the tension controller;
3、設定涂布工作方式和相關參數（涂布速度、段長、間隙長度、輥速比等），而后接通壓縮空氣（調節氣動控制箱調壓閥使氣動壓力在0.2~0.3Mpa之間）；
3. Set the coating working mode and relevant parameters (coating speed, section length, gap length, roll speed ratio, etc.), and then connect the compressed air (adjust the pressure regulating valve of the pneumatic control box to make the pneumatic pressure between 0.2 ~ 0.3MPa);
4、啟動干燥風機和干燥溫控儀；
4. Start the drying fan and drying temperature controller;
5、接通自動糾偏和張力控制器電源；
5. Turn on the power supply of automatic deviation correction and tension controller;
6、設備各段溫度均已達到工藝要求溫度；
6. The temperature of each section of the equipment has reached the temperature required by the process;
7、給涂布裝置料斗加料，同時啟動涂布機，進行涂布。
7. Feed the hopper of the coating device and start the coater for coating at the same time.
維持涂布機的正常運行，要按照涂布機操作規程進行：
To maintain the normal operation of the coater, it is necessary to follow the operating procedures of the coater:

涂布機的開機前準備：
Preparation before startup of coater:
1、檢查各電氣開關，聯線有無脫落或破損等異?，F象；
1. Check whether all electrical switches and connecting wires fall off or are damaged;
2、按工藝片路要求在常溫停機狀態下穿好牽引帶；
2. Put on the traction belt under normal temperature shutdown according to the process requirements;
3、啟動排風設備；
3. Start the exhaust equipment;
4、確認在涂布機房內無任何明火（如電爐等）；
4. Confirm that there is no open fire in the coating machine room (such as electric furnace);
5、涂布機控制柜和干燥箱體外殼可靠接地。
5. The control cabinet of the coater and the shell of the drying box are reliably grounded.
