Basic process of automatic gluing

1.測寬：一次使用或鋁框寬度改變后，需要對鋁條進行測寬，以便傳送時鋁框順利通過膠嘴。

1. Width measurement: after one use or the width of the aluminum frame is changed, it is necessary to measure the width of the aluminum strip so that the aluminum frame can pass through the rubber nozzle smoothly during transmission.

2.加熱：進入自動狀態后，膠嘴和膠盤要行加熱，同時傳送帶轉動，以免膠嘴溫度升高后將傳送帶燙壞，溫度高于80度以后打膠流程才會起效。

2. Heating: after entering the automatic state, the rubber nozzle and the rubber disk shall be heated first, and the conveyor belt shall be rotated at the same time to avoid burning the conveyor belt after the temperature of the rubber nozzle rises. The gluing process will not take effect until the temperature is higher than 80 ℃.

3.傳送打膠：當達到設定溫度后，手持鋁框放在傳送帶上，當前端打膠光電檢測到鋁框時，自動涂膠過程開始。打膠光電有信號后，延時一段時間，前壓輪下壓，壓住鋁框；前壓輪下壓后延時一段時間，膠缸前進，膠嘴出膠。開始涂膠后，再延時一段時間，后壓輪下壓。打膠光電信號消失后，延時一段時間，前壓輪抬起，前壓輪抬起后，再延時一段時間，膠缸停止前進，同時膠嘴停止涂膠；停止涂膠后，再延時一段時間后，后壓輪抬起，鋁框一邊涂膠完成。

3. Transfer gluing: when the set temperature is reached, put the aluminum frame on the conveyor belt by hand. When the front end gluing photoelectric detects the aluminum frame, the automatic gluing process starts. After there is a signal from the gluing photoelectricity, delay for a period of time, and press down the front pressing wheel to press the aluminum frame; After the front pressure roller is pressed down, the rubber cylinder will advance and the rubber nozzle will release rubber. After the start of gluing, delay for a period of time and press down the rear pressure roller. After the photo electric signal of gluing disappears, delay for a period of time, the front pressure wheel is lifted, and after the front pressure wheel is lifted, delay for a period of time, the glue cylinder stops moving and the glue nozzle stops gluing; After stopping the gluing, after a period of time, the rear pressure roller will be lifted and the gluing on one side of the aluminum frame will be completed.

之后重復傳送打膠流程，將鋁框剩余三邊全部涂上丁基膠，鋁框涂膠就全部完成。

After that, repeat the transfer and gluing process, coat the remaining three sides of the aluminum frame with butyl glue, and the gluing of the aluminum frame is completed.

因為大多數鋁框為方形而少數為圓形，所以在自動中可以進行方形和圓形的切換。當為圓形框涂膠時，中間壓輪壓住圓框，同時皮帶轉動，膠嘴出膠，松開腳踏開關該過程停止。

Since most of the aluminum frames are square and a few are round, you can switch between square and round in automatic. When the round frame is coated with glue, the intermediate pressure roller presses the round frame, and the belt rotates, the glue nozzle is released, and the process stops when the foot switch is released.
